DUCT FREE SYSTEMS
Duct free heating and cooling systems make your home's individual rooms or other small spaces more comfortable. Remember, just like whole-home systems, the higher the SEER/SEER2 and HSPF/HSPF2 ratings, the more efficient they will be.
The DOE’s regional breakdown by state is as follows:
- North
- 14.0 SEER/ 13.4 SEER2
- 8.8 HSPF/7.5 HSPF2
- Southeast
- 15.0 SEER/ 14.3 SEER2
- 12.2 EER/11.7 EER2
- 8.8 HSPF/7.5 HSPF2
- Southwest
- 15.0 SEER/ 14.3 SEER2
- 12.2 EER/11.7 EER2
- 8.8 HSPF/7.5 HSPF2
SEER/SEER2 AND HSPF/HSPF2
SEER2 is an updated rating standard introduced by the DOE. SEER2 standards are intended to provide a better gauge of typical home operating conditions whereas the older SEER rating utilized very precise protocols to determine ratings in ideal conditions. SEER2 standards include updated testing means that give a better indication of how a unit will operate in the real world.
HSPF2 is the newest type of rating system that expands on the basic HSPF scale.
Much like miles-per-gallon for a car, SEER/SEER2, EER/EER2 and HSPF/HSPF2 offer an easy way to compare efficiencies of different products – the higher the rating, the more efficient the unit. Just be sure you are comparing either SEER vs SEER or SEER2 vs SEER2 (same for EER/EER2 and HSPF/HSPF2).
EER2 VS. SEER2
EER2 and SEER2 both evaluate an air conditioner’s energy efficiency, but they’re concerned with two different types of temperature conditions:
- EER2 measures an air conditioner’s efficiency at the peak cooling temperature of 95°F.
- SEER2 measures an air conditioner’s efficiency throughout an entire cooling season, with temperatures ranging from 65°F to 104°F.
CALL ELITE SERVICE CO. LLC TO FIND OUT IF DUCT-FREE SYSTEMS ARE RIGHT FOR YOU.
We offer a variety of through-the-wall packaged terminal air conditioners (PTAC) and duct free heating and cooling systems to meet any individual room's needs.
Call us now at 706-287-5887.
DUCTLESS HIGH WALL INDOOR HEAT PUMPS
DAIKIN DUCTLESS SYSTEM LV SERIES SINGLE ZONE WALL-MOUNT UNIT
| Model Family: FDXS**LVJU |
|---|
| Purpose: Heating and Cooling |
| Zone Capability: Single zone |
| Efficiency SEER/SEER2: Up to 15.5 SEER |
| Efficiency EER/EER2: up to 12.5 EER |
| Efficiency HSPF/HSPF2: Up to 10.4 HSPF |
| Matching Outdoor Unit: Single-Zone: RXS**LVJU |
| Matching Outdoor Unit: Multi-Zone: N/A |
| Energy Star Rated: ENERGY STAR® |
| Refrigerant Type: R-410A |
| Number of Fan Speeds: N/A |
| Sound Level: Quiet operation |
| Wireless Remote: N/A |
| Factory Warranty Parts: 12 Year Parts Warranty |
Manufacturer's Stated Benefits:
- Econo Mode function reduces operating current and power consumption by approximately 30% during start-up
- Desired temperature quickly achieved with rapid cooling or heating via powerful operation
- Precision temperature control for individual rooms
DAIKIN DUCTLESS SYSTEM 19 SERIES SINGLE ZONE WALL-MOUNT
| Model Family: RX**AXVJU |
|---|
| Purpose: Heating and Cooling |
| Zone Capability: Single zone |
| Efficiency SEER/SEER2: Up to 19 SEER |
| Efficiency EER/EER2: up to 12.5 EER |
| Efficiency HSPF/HSPF2: Up to 10 HSPF |
| Matching Outdoor Unit: Single-Zone: RX**NMVJU |
| Matching Outdoor Unit: Multi-Zone: N/A |
| Energy Star Rated: ENERGY STAR® |
| Refrigerant Type: R-410A |
| Number of Fan Speeds: N/A |
| Sound Level: Quiet operation |
| Wireless Remote: Yes |
| Factory Warranty Parts: 12 Year Limited Parts Warranty |
Manufacturer's Stated Benefits:
- Econo Mode function reduces operating current and power consumption by approximately 30% during startup
- Effective heating and cooling throughout the room via wide-angle louvers and vertical auto-swing function
- Precision temperature control for individual rooms
- Econo-mode decreases power consumption when other appliances need more power
- Titanium Apatitie air-purifying filter
- Refrigerant leakage detection
- Wide-angle louvers
- Vertical auto-swing
- Automatic operation with auto-restart
- Auto-fan speed
- Wipe-clean flat pane
- Comfort mode
- Self-diagnosis with digital display
- Anti-corrosion treatment
DAIKIN ALTERNATE INDOOR DUCTLESS PRODUCTS
DAIKIN VISTA™ CEILING CASSETTE SINGLE ZONE INDOOR UNIT
| Model Family: FFQ**W2VJU9 |
|---|
| Purpose: Heat and Cool |
| Zone Capability: Single zone |
| Efficiency SEER/SEER2: 19.8 SEER2 |
| Efficiency EER/EER2: Up to 12 EER2 |
| Efficiency HSPF/HSPF2: Up to 9.4 HSPF2 |
| Matching Outdoor Unit: Single-Zone: RX0^^WMVJU9 |
| Matching Outdoor Unit: Multi-Zone: N/A |
| Energy Star Rated: N/A |
| Refrigerant Type: R-410A |
| Number of Fan Speeds: Turbo Fan, 3 Steps, Quiet, Auto |
| Sound Level: Quiet operation |
| Wireless Remote: Yes |
| Factory Warranty Parts: 12-Year Parts Limited Warranty |
Manufacturer's Stated Benefits:
- Seamless integration in standard architectural ceiling tiles, leaving only 5/16”.
- No optional adaptor needed for DIII-connection, link your unit into the wider building management system
- Optional Fresh air integration possible
- Blend of iconic design and engineering excellence with an elegant finish in white or a combination of silver and white
- Reduced energy consumption thanks to small tube heat exchanger, DC fan motor, and two optional intelligent sensors
- Optional Wired Controller available
DAIKIN MULTI-ZONE SYSTEMS INDOOR FDMQ UNIT DUCTED CONCEALED
| Model Family: FDMQ**RVJU |
|---|
| Purpose: Heat and Cool |
| Zone Capability: Multi Zone |
| Efficiency SEER/SEER2: Up to 17.9 SEER2 |
| Efficiency EER/EER2: Up to 10.5 EER2 |
| Efficiency HSPF/HSPF2: Up to 8.75 HSPF2 |
| Matching Outdoor Unit: Single-Zone: N/A |
| Matching Outdoor Unit: Multi-Zone: |
| Energy Star Rated: No |
| Refrigerant Type: R410A |
| Number of Fan Speeds: 5 Steps, Quiet, Auto |
| Sound Level: As low as 32 dB(A) |
| Wireless Remote: Yes |
| Factory Warranty Parts: 12 Parts Limited Warranty |
Manufacturer's Stated Benefits:
- No optional adaptor needed for DIII-connection, link your unit into the wider building management system
- Self-Diagnostics with digital display
- Program Dry Function
- Compatible with DKN Cloud Wi-Fi Adaptor
DAIKIN AURORA SINGLE ZONE FLOOR-MOUNTED HEAT PUMP
| Model Family: FVXS**NVJU |
|---|
| Purpose: Heat and Cool |
| Zone Capability: Single zone |
| Efficiency SEER/SEER2: Up to 19.5 SEER2 |
| Efficiency EER/EER2: 11.5 EER2 |
| Efficiency HSPF/HSPF2: Up to 9.7 HSPF |
| Matching Outdoor Unit: Single-Zone: RXL**QMVJU |
| Matching Outdoor Unit: Multi-Zone: N/A |
| Energy Star Rated: ENERGY STAR® |
| Refrigerant Type: R-410A |
| Number of Fan Speeds: 5 Steps, Quiet, Auto |
| Sound Level: 32 dB indoor; 50 dB outdoor |
| Wireless Remote: Yes |
| Factory Warranty Parts: 12-Year Parts Limited Warranty |
Manufacturer's Stated Benefits:
- Program Dry Function
- Auto Fan Speed Control
- Auto Changeover
- Washable Air Filter
- Econo Mode
- Auto Restart after Power Failure
- Quick warming function
- Hot start function
- Automatic defrosting
DUCTLESS HIGH WALL INDOOR AIR CONDITIONERS
DUCTLESS SYSTEM 19 SERIES SINGLE ZONE WALL-MOUNT COOLING ONLY
| Model Family: FTK**NMVJU |
|---|
| Purpose: Cooling |
| Zone Capability: Single zone |
| Efficiency SEER/SEER2: Up to 19 SEER |
| Efficiency EER/EER2: 12.5 EER |
| Matching Outdoor Unit: Single-Zone: RK**NMVJU |
| Matching Outdoor Unit: Multi-Zone: N/A |
| Energy Star Rated: ENERGY STAR® |
| Refrigerant Type: R-410A |
| Number of Fan Speeds: N/A |
| Sound Level: Quiet operation |
| Wireless Remote: Yes |
| Factory Warranty Parts: 12 Year Parts Limited Warranty |
Manufacturer's Stated Benefits:
- Program Dry Function
- Econo Mode
- Powerful Operation Mode
- Auto Fan Speed Control
- Auto Restart after power failure
- Self-Diagnostics with digital display
- Washable Air Filter
